PV (DC Input)
|
Recommended Max. PV Input Power |
6000W |
|
Max. Input Voltage |
500V |
|
MPT Operating Voltage Range |
85V-450V (@75V start up) |
|
Number of MPPT |
1 |
|
Max. Number of Input Strings Per MPPT |
1 |
|
Max. input Current Per MPPT |
27A |
|
Max. Short-Circuit Current Per MPPT |
35A |
|
Grid (AC Input) Max output power |
6000W |
|
Max output current |
50A |
|
Rated grid voltage |
220/230/240V (L, N, PE) |
|
Rated grid frequency |
50/60Hz |
|
Acceptable range |
170-280 Vac (for UPS) 90-280 Vac (for home application) |
|
Battery Parameters (Bidirection) Battery type |
LiFePO4 |
|
Battery voltage range |
40-60 Vdc |
|
Battery capacity |
10.24kWh |
|
Rated Battery Voltage |
48Vdc/51.2Vdc |
|
Max. charge/discharge current |
120A / 130A |
|
BMS Communication Mode |
Software Version |
|
Back-up Output (AC output) Rated output power |
6000W/6000VA |
|
Rated output current |
27.3A |
|
Rated output voltage / Frequency |
220/230/240V (L, N, PE) 50/60Hz |
|
Surge power THDV (@ linear load) |
12000VA 5s < 3% |
|
Efficiency Peak Efficiency |
98% |
|
Max. MPPT Efficiency |
99.90% |
|
IP Rating |
IP21 |
|
General Parameters Operating temperature range |
-10°C ~50°C |
|
Relative humidity range |
10%~95% |
|
Max. operating altitude |
>2000m derating |
|
Standby self-consumption |
<10 W |
|
Installation type |
Installation type |
|
Cooling mode |
Fan Cooling |
|
Dimension D*W*H |
450x450x515(mm) |
|
Weight |
~118kg |
