| Place Of Origin | China | Voltage | 51.2 V |
| Net Weight | 8.26kg | Communication Port | CAN, RS232, RS485, RS485,CAN |
| Type | All-In-One | Installation | Wall Or Floor Mounted |
| Protection Class | IP65 | Transportation | UN38.3 |
| Capacity Ah | 100 Ah | Working Temp | -20 - 60°C |
| Cycle Life | >6000 Times | Inverter Power | 6.2kW |
| Monitoring | Real - Time Monitoring And Control | System Type | Stackable |
| Chargeable | Yes | Application | Household Solar Energy |
| Highlight | 5kw inverter solar ESS, 5KWH solar ESS, lifepo4 lithium battery solar ESS |
Product Description
Rated Voltage | 25.6V | 51.2V | 51.2V | 51.2V | 51.2V |
Rated Capacity | 200Ah | 100Ah | 200Ah | 280Ah | 560Ah |
Rated Energy | 5.12kWh | 5.12kWh | 10.24kWh | 14.34kWh | 28.67kWh |
Output Voltage Range | 21.6V~29.2V | 43.2V~58.4V | 43.2V~58.4V | 43.2V~58.4V | 43.2V~58.4V |
Charging Voltage | 28.8~29.2V | 57.6~58.4V | 57.6~58.4V | 57.6~58.4V | 57.6~584V |
Cut-off Voltage | 21.6V | 43.2V | 43.2V | 43.2V | 43.2V |
Max. Charging Current | 150A | 100A | 150A | 200A | 200A |
Recommended Charging Current | 50A | 50A | 50A | 100A | 100A |
Max. Discharging Current | 150A | 100A | 150A | 200A | 200A |
Efficiency | >98% | >98% | >98% | >98% | >98% |
Dimension L*W*H (mm) | 600*480*200 | 600*480*200 | 750*640*200 | 700*550*255 | 850*870*255 |
Weight (kg ) | ~45 | ~45 | ~95 | ~117 | ~215 |
Humidity 5%~95% Relative humidity | |||||
Charging Temperature | 0°C~55°C | ||||
Discharging Temperature | -20°C~60°C | ||||
Storage Temperature | -10°C~30°C | ||||
Cycle Life | > 6000 times (0.20, @25°C, 80%DOD) | ||||
Design Life | >10 years | ||||
