PV (DC Input)
|
Recommended Max. PV Input Power |
12000W |
|
Max. Input Voltage |
500V |
|
MPT Operating Voltage Range |
85V-450V (@75V start up) |
|
Number of MPPT |
2 |
|
Max. Number of Input Strings Per MPPT |
1 |
|
Max. input Current Per MPPT |
27A/13A(MAX:40A) |
|
Max. Short-Circuit Current Per MPPT |
37A/17.5A |
|
Grid (AC Input) Max output power |
12000W |
|
Max output current |
70A |
|
Rated grid voltage |
220/230/240V (L, N, PE) |
|
Rated grid frequency |
50/60Hz |
|
Acceptable range |
170-280 Vac (for UPS) 90-280 Vac (for home application) |
|
Battery Parameters (Bidirection) Battery type |
LiFeP04 |
|
Battery voltage range |
40-60 Vdc |
|
Battery capacity |
15.36kWh |
|
Rated Battery Voltage |
48Vdc/51.2Vdc |
|
Max. charge/discharge current |
210A / 240A |
|
BMS Communication Mode |
Software Version |
|
Back-up Output (AC output) Rated output power |
12000W/12000VA |
|
Rated output current |
54.5A |
|
Rated output voltage / Frequency |
220/230/240V (L, N, PE) 50/60Hz |
|
Surge power |
22000VA 5s |
|
THDV (@ linear load) |
< 3% |
|
Efficiency Peak Efficiency |
98% |
|
Max. MPPT Efficiency |
99.90% |
|
IP Rating |
IP21 |
|
General Parameters Operating temperature range |
-10°C ~ 50°C |
|
Relative humidity range |
10%~95% |
|
Max. operating altitude |
>2000m derating |
|
Standby self-consumption |
<20 W |
|
Installation type |
Installation type |
|
Cooling mode |
Fan Cooling |
|
Dimension D*W*H |
650x360x970(mm) |
|
Weight |
=160.5kg |
